LED Crane Lighting Solutions

Docker Series

An LED floodlighting solution designed for applications requiring high performance and high durability. Featuring a full AISI 316 stainless steel body built to resist the harshest environments. The Midstream Docker Series provides LED Crane floodlights to ensure maintenance-free operation for a range of critical applications in maritime environments.

Features and benefits of the Docker Series:

  • Heavy Duty LED floodlights built to resist the harshest environments and for applications needing high performance and high durability.
  • A low weight design and compact size allows for an easy to install solution.
  • Designed with a wide range of optics to provide a solution that maximises safety across all areas and allows for the provision of a tailor-made crane lighting layout for your environment, using the optimum choice of optics to
    reduce glare, increase uniformity and avoid any dark spots on the ground.
  • Manufactured with Midstreams proprietary Asymmetric optic that guarantees a wide coverage of luminance levels for improved obstacle recognition and the light emission allows light to cover an area four times larger than currently achievable with traditional symmetric optics, removing the need for additional front-facing floodlights for example on cranes, resulting in a low glare installation.
  • Manufactured with 316 stainless steel to resist corrosion in harsh, saline environments.
  • Certified IP 67 for highest level of ingress protection.
  • Tested on STS & RTG Cranes.
  • Tested for Salt spray for 1000h according to ASTM B117 and for Vibrations up to 6G and 100.000 Cycles
    according to ANSI C136.31-2010.
  • UL certified and DLC listed (US Version)

APPLICATIONS

  • Maritime
  • RTG Cranes
  • STS Cranes
  • Bulk Handling Cranes
  • Construction sites
  • Mining operations
  • Military applications
  • Mobile Equipment
Hupac Crane Lighting
Maritime Led Lighting
Maritime Led Lighting

The products

  • DOCKER 150
  • DOCKER 300

DOCKER 150

DOCKER 300

TECHNICAL SPECS

PHOTOMETRICS

FH

S1

S2

S3

S4

S5

ORDERING CODES



Product Family Power Optic CCT CRI Voltage Input Control System Body Type Bracket Optional
D (Docker) 15 FH A (5000k) 70 EU (100-277 VAC) 10 (0-10v) M (AISI 316 SS) A (Type A) 00
30 S1 B (4000k) 80 US (277-480 VAC) B (Type B)
S2 C (3000K) 90
S3 D (5700k)
S4
S5

RESOURCES

Docker 150 (EU) Tech Specification English (pdf 785.17 KB)
Docker 150 (US) Tech Specification English (pdf 149.62 KB)
Docker 300 (US) Tech Specification English (pdf 149.77 KB)
Docker 300 Tech spec (pdf 159.02 KB)
